Softcover – 222 pages. – Triumph 650 750 2-Valve Unit Twins 1963 – 1983 Haynes Owners Service Repair Manual Covers the Following Models: T6 Thunderbird 1963 – 1966 TR6 Trophy 1963 – 1971 TR6R Tiger 1970 – 1973 T120 Bonneville 1963 – 1975 TR65 Thunderbird 1982 – 1983 TR65T Tiger Trail 1982 T140V Bonneville 1973 – 1978 T140V Bonneville Jubilee 1977 T140E Bonneville 1978 – 1983 T140D Bonneville Special 1979 – 1983 T140ES Bonneville Electro 1980 – 1983 T140EX Bonneville Executive 1981 – 1983 T140LE Bonneville Royal 1981 TR7V Tiger 1973 – 1978 TR7 Tiger 1978 – 1981 TR7T Tiger Trail 1981 -1982 TSX 2-valve 744cc 1981 – 1983Contents About this manual Introduction to the Triumph 650 750cc unit construction vertical twins Guide to machine identification Ordering spare parts Routine maintenance Safety first! Chapter 1 – Engine Chapter 2 – Gearbox Chapter 3 – Clutch and primary transmission Chapter 4 – Fuel system and lubrication Chapter 5 – Ignition system Chapter 6 – Frame and forks Chapter 7 – Wheels brakes and final drive Chapter 8 – Electrical system Chapter 9 – The 1975 to 1983 models Wiring diagrams Metric conversion tables Conversion factors click the link
