Toyota 22R and 22R-E engine factory workshop and repair manual

click here to learn more
Toyota 22R and 22R-E engine factory workshop and repair manual on PDF can be viewed using PDF reader like adobe or foxit or nitro . File size 18 Mb Searchable PDF document with bookmarks. Covers Maintenance Engine Mechanical EFI Fuel System Cooling System Lubrication Syste Ignition System Starting SystemCharging SystemAbout the 22R engine The Toyota R family was a variety of straight-4 gasoline engines. Created for longitudinal use in such cars as the Celica and Hilux and in manufacturing from 1953 through 1995 use faded out as numerous of Toyota s mainstream models relocated to front-wheel drive. OHC versions featured a chain-driven camshaft mitigating the danger of internal damage from interference as in belt-driven engines.The 2-valve SOHC 2.4 L (2 366 cc) 22R was produced from 1981 through 1995.Cylinder bore was 91.9 mm (3.62 in) and stroke was 88.9 mm (3.5 in).Initial output was 97 hp (72 kW) at 4 800 rpm and 129 lbA? further data
