Toyota 22R and 22R-E engine factory workshop and repair manual downloadon PDF can be viewed using PDF reader like adobe or foxit or nitro . File size 18 Mb Searchable PDF document with bookmarks. Covers Maintenance Engine Mechanical EFI Fuel System Cooling System Lubrication Syste Ignition System Starting SystemCharging SystemAbout the 22R engine The Toyota R family was a variety of straight-4 gasoline engines. Created for longitudinal use in such cars as the Celica and Hilux and in manufacturing from 1953 through 1995 use faded out as numerous of Toyota s mainstream models relocated to front-wheel drive. OHC versions featured a chain-driven camshaft mitigating the danger of internal damage from interference as in belt-driven engines.The 2-valve SOHC 2.4 L (2 366 cc) 22R was produced from 1981 through 1995.Many parts from the newer 22R-E are not compatible with those from the older pre-1985 engine. Non-compatible areas include the cylinder head block pistons and numerous of the connected parts such once the timing chain and cover and water and oil pumps (although the oil pump internals are the same). These changean in addition affected the 22R therefore one can give consideration to the 85-95 22R-E as a fuel injected version of the 85-90 22R with only small differences if any.Toyota swapped the dual row timing chain found in old engines for a unmarried row company with plastic guides in 1983. This program decreased pull on the system but was occasionally problematic. Every 80 000 to 140 000 kilometers the chain would occasionally stretch to the point that the hydraulic-operated chain tensioner can not take up any more slack. Whenever this happens the moment chain impacts the driver s side chain guide breaking the plastic within a few hundred miles of driving and adding lots more
