Suzuki QuadRacer LT250R 1985 – 1992 Clymer Owners Service and Repair Manual

purchase
Softcover. 324 pages – – Suzuki QuadRacer LT250R 1985 – 1992 Clymer Owners Service Repair Manual Covers the Suzuki LT250R QuadRacer 1985 to 1992 models.Contents QUICK REFERENCE DATA GENERAL INFORMATIONManual organization / Notes cautions and warnings / Service hints / Torque specifications / Safety first / Special tips / Expendable supplies / Parts replacement / Serial numbers / Basic ahnd tools / Tune-up and troubleshooting tools / Mechanic s tips / Of Road Rules / Riding safely TROUBLESHOOTINGOperating requirements / Emergency troubleshooting / Engine starting / Engine performance / Engine noises / Excessive vibration / Front suspension and steering / Brake problems LUBRICATION MAINTENANCE AND TUNE-UPPre-checks / Engine lubrication / Service intervals maintenance schedule / Tyres and wheels / Periodic lubrication / Transmission clutch oil change / Control throttle clutch parking brake cable lubrication / Periodic maintenance / Drive chain adjustment / Fuel shut off valve and filter inspection / Air filter / Engine tune-up / Cylinder head nut torque / Spark plug plugs / Idle speed adjustment / Carbon removal / Specifications ENGINE (1985-1986 MODELS) Engine operating principles / Engine lubrication / Servicing the engine in the frame / Engine removal and installation / Cylinder head / Cylinder / Reed valve assembly / Piston piston pin and piston rings / Primary drive gear balancer drive gear balancer driven gear and water pump drive gear / Magneto / Drive sprocket / Kickstarter / Crankcase and crankshaft / Break-in procedure / Specifications ENGINE (1987 AND LATER MODELS) Engine operating principles / Engine lubrication / Servicing the engine in the frame / Engine removal and installation / Cylinder head / Cylinder / Reed valve assembly / Exhaust valve / Piston piston pin and piston rings / Primary drive gear balancer drive gear balancer driven gear and water pump drive gear / Magneto / Drive sprocket / Kickstarter / Crankcase and crankshaft / Break-in procedure / Specifications CLUTCH AND TRANSMISSION (1985-1986 MODELS) Clutch operation / Clutch release mechanism / Cable / External shift mechanism / Transmission and internal shift mechanism / Specifications CLUTCH AND TRANSMISSION (1987 AND LATER MODELS) Clutch operation / Clutch release mechanism / Cable / External shift mechanism / Transmission and internal shift mechanism / Specifications FUEL AND EXH come here
