Suzuki GSX1300R Hayabusa 1999 – 2007 Clymer Owners Service and Repair Manual

shop
Softcover – 426 pages – Suzuki GSX1300R Hayabusa 1999 – 2007 Clymer Owners Service Repair Manual covers Suzuki GSX1300R Hayabusa sport bikes 1999 – 2007. The Suzuki Hayabusa GSX1300R features a liquid-cooled four-valve in-line four cylinder engine with dual camshafts driven by a single cam chain.CONTENTS: QUICK REFERENCE DATA GENERAL INFORMATIONManual organization / Warnings cautions and notes / Safety / Serial numbers / Fasteners / Shop supplies / Tools / Measuring tools / Electrical system fundamentals / Service methods / Storage / Specifications TROUBLESHOOTINGEngine starting / Engine will not start / Engine performance / Lubrication system / Leakdown test / Clutch / Gearshift linkage / Transmission / Fuel system / Fuel pump / Electrical testing / Electrical systems / Steering and suspension / Brake system / Specifications LUBRICATION MAINTENANCE AND TUNE-UPMaintenance intervals shedule / Tune-up / Ignition timing / Valve clearance / Spark plugs / Engine oil and filter / Engine oil pressure / Throttle cable free play / Idle speed adjustment / Fast idle speed / Throttle body synchronization / Fuel line inspection / Emission control systems / Control cable / Fasteners / Specifications ENGINE UPPER ENDCylinder head cover / Camshaft / Cam chain tensioner / Cam chain and chain guides / Cylinder head / Valve lifters and shims / Valves and valve components / Cylinder block / Piston and piston rings / Specifications ENGINE LOWER ENDEngine service notes / Engine / Starter idler gear / Starter clutch and gears / Alternator cover / Flywheel / Oil pump / Oil cooler / Oil catch tank / Oil pan and strainer / Crankcase / Balancer / Crankshaft / Connecting rod / Engine break-in / Specifications CLUTCHClutch bleeding / Draining the system / Clutch cover / Clutch master and slave cylinder / Clutch hose replacement / Specifications TRANSMISSION SHIFT MECHANISM AND ENGINE SPROCKETEngine sprocket cover / Engine sprocket / Shift pedal / External and internal shift mechanism / Specifications AIR FUEL INJECTION EXHAUST AND EMISSIONS SYSTEMSDepressurizing the fuel system / Fuel tank / Fuel pump / Fuel level sender / Fuel pump relay / Pressure regulator / Air filter housing / Intake air control system / Heat shield / Throttle bodies / Fuel injector / Throttle position TP sensor / Throttle cable replacement / Fast idle choke / Atmospheric pressure AP sensor / Camshaft position se much more info
