Mazda 323 Protege 1990-2003 Haynes Service Repair Manual

bookstore
USA Haynes manual covering Mazda 323 and Protege 1990 – 2003 Haynes Owners Service . (This generation 323 was known in Australia as the BG-series)Engines covered: 1489 cc (1.5 litre) Z5 DOHC 4 cylinder 1598 cc (1.6 litre) B6 SOHC 4 cylinder 1598 cc (1.6 litre) ZM DOHC 4 cylinder 1840 cc (1.8 litre) BP SOHC DOHC 4 cylinder 1840 cc (1.8 litre) FP DOHC 4 cylinder IntroductionChapter 1: Tune-up and routine maintenanceChapter 2: Part A: EnginesChapter 2: Part B: General engine overhaul proceduresChapter 3: Cooling heating and air conditioning systemsChapter 4: Fuel and exhaust systemsChapter 5: Engine electrical systemsChapter 6: Emissions and engine control systemsChapter 7: Manual and automatic transaxlesChapter 8: Clutch and driveaxlesChapter 9: BrakesChapter 10: Suspension and steering systemsChapter 11: BodyChapter 12: Chassis electrical systemWiring Diagrams Please note: This manual does not include information specific to 4WD models. Inside this manual you will find: Routine Maintenance tune-up procedures engine repair cooling and heating air-conditioning fuel and exhaust emissions control ignition brakes suspension and steering electrical systems and wiring diagrams. Haynes repair manuals can save you money on maintenance and repair bills. Step-by-step procedures and illustrations guide you through every job from basic maintenance and troubleshooting to complete teardown rebuild. details
