Honda 50cc – 110cc OHC Singles 1965 – 1999 Clymer Owners Service and Repair Manual

Softcover – 390 pages – Honda 50cc – 110cc OHC Singles 1965 – 1999 Clymer Owners Service Repair Manual Covers the following Models: Honda Z50A 1969-1978 Honda Z50R 1979-1989 1991-1999 Honda S65 all years Honda C70 1980-1983 Honda C70M all years Honda CL70 all years Honda CT70 1969-1982 Honda SL70 1971-1972 Honda XL70 1974-1976 Honda S90 1973-1975 Honda SL90 all years Honda ST90 1973-1975 Honda CL90 all years Honda CL90L all years Honda CT90 1969-1979 Honda CT110 1980-1984 1986Please note: This manual DOES NOT include ZB50. Please see CM319-2 for 1997 – 2003 XR70R models.Contents ; QUICK REFERENCE DATA GENERAL INFORMATIONManual organization / Service hints / Safety first / Parts replacement / Expendable supplies / Specifications TROUBLESHOOTINGOperating requirements / Emergency requirements / Emergency troubleshooting / Engine starting problems / Operating problems / Clutch / Brakes / Transmission / Suspension LUBRICATION MAINTENANCE AND TUNE-UPDaily checks / Routine checks / Service intervals / Crankcase breather hoses / Battery / Periodic lubrication / Engine oil change / Centrifugal oil filter rotor and oil filter screen cleaning / Fork oil change / Drive chain lubrication / Control cable service / Speedometer cable lubrication / Drive chain adjustment / Front brake adjustment / Rear brake adjustment / Centrifugal clutch adjustment / Manual clutch adjustment / Throttle adjustment / Air filter service / Fuel shutoff valve and filter service / Periodic maintenance / tune-up / Air cleaner element / Valve clearance adjustment / Camshaft chain tensioner adjustment / Compression test / Spark plugs / Contact breaker point ignition / Solid state ignition / Carburetor / Idle mixture adjustment / idle speed adjustment / Serial numbers / Specifications ENGINEEngine lubrication / Removal installation / Cylinder head and camshaft / Valves and valve components / Camshaft chain and tensioner / Cylinder / Piston pins and rings / Ignition advance mechanism / Alternator / Oil pump / Crankcase and crankshaft / Kickstarter / Electric starter gears / Break-in procedure / Specifications CLUTCH AND TRANSMISSIONManual clutch / Centrifugal clutch / Clutch inspection / Clutch release mechanism removal/installation / Clutch cable / External shift mechanism / Drive sprocket / Transmission and internal shift mechanism / Preliminary transmission inspection / 3-speed transmission and click on
