Yamaha XT600 and TT600 1983 – 1989 Clymer Owners Service and Repair Manual

click here to learn more
Softcover – 472 pages – Yamaha XT600 TT600 1983 – 1989 Clymer Owners Service Repair Manual Covers the following Models: XT600 (1984 – 1989) TT600 (1983 – 1986)Contents: QUICK REFERENCE DATA GENERAL INFORMATIONManual organization / Notes cautions and warnings / Safety first / Service hints / Washing the bike / Torque specifications / Fasteners / Lubricants / Expendable supplies / Parts replacement / Emission control and battery decals (XT600) / Basic hand tools / Precision measuring tools / Special tools / Mechanic #39;s tips / Riding safety / Specifications TROUBLESHOOTINGOperating requirements / Troubleshooting instruments / Starting the engine / Starting difficulties / Engine starting troubles / Engine performance / Engine noises / Excessive vibration / Clutch / Transmission / Ignition system / Front suspension and steering / Brakes LUBRICATION MAINTENANCE AND TUNE-UPPre-checks / Tyres and wheels / Lubricants / Battery (XT600) / Periodic lubrication / Engine oil and filter change / Oil pressure check / Front fork oil change / Drive chain / Speedometer and tachometer cable lubrication / Swing arm and relay arm lubrication / Periodic maintenance / Drive chain adjustment / Throttle cable adjustment / Decompression cable adjustment / Air filter service / Front fork air pressure / Engine tune-up / Valve clearance measurement and adjustment / Storage / Compression test / Spark plug / Ignition timing / Carburetor idle speed adjustment / Specifications ENGINE TOP ENDEngine principles / Servicing engine in frame / Lowering engine in frame / Cylinder head cover and rocker arms / Camshaft and tensioner / Cylinder head / Camshaft chain guides / Valves and valve components / Cylinder block / Piston / Piston rings / Specifications ENGINE LOWER ENDServicing engine in frame / Engine removal installation / Crankcase and crankshaft / Break-in procedure / Specifications CLUTCH KICKSTARTER AND EXTERNAL SHIFT MECHANISMClutch cover and decompression lever / Clutch / Clutch release mechanism / Primary drive gear balancer drive and driven gears / Camshaft chain and rear guide / Kickstarter / Oil pump / Oil tank and oil hoses / External shift mechanism / Clutch cable / Specifications TRANSMISSION AND INTERNAL SHIFT MECHANISMTransmission operation / Transmission troubleshooting / Transmission overhaul / Internal shift mechanism / Specifications FUEL EXHAUST AND EMISSION CONTROL more data
