Honda XL/XR600R and XR650L/R 1983 – 2008 Haynes Owners Service and Repair Manual

service manual
Softcover – 320 pages – Honda XL/XR600R XR650L/R 1983 – 2008 Haynes Owners Service Repair Manual Covers the following Models: Honda XL600R (589cc) 1983 – 1987 Honda XR600R (591cc) 1985 – 2000 Honda XR650L (664cc) 1993 – 2008 Honda XR650R (649cc) 2000 – 2007Contents: Honda XL Honda XR Mainenance- Routine Maintenance And Servicing- Engine/Transmission Oil Level Check- Coolant Level Check- Brake Fluid Level Checks- Tyre Checks- Specifications- Recommended Lubricants And Fluids- Maintenance Schedule- Component Locations- Maintenance Procedures Repairs And Overhaul- Engine Transmission And Associated Systems- Engine (Air-Cooled) Clutch And Transmission- Engine (Liquid-Cooled) Clutch And Transmission- Cooling System (Xr650r Models)- Fuel And Exhaust Systems- Ignition And Electrical Systems Chassis Components- Steering- Suspension- Final Drive- Brakes- Wheels- Tyres- Frame And Bodywork Electrical System- Wiring Diagrams Reference- Dimensions And Weights- Tools And Workshop Tips- Storage extra
