Honda TRX450R and TRX450ER ATV 2004 – 2009 Clymer Owners Service and Repair Manual

click here to learn more
Softcover – 420 pages – Honda TRX450R TRX450ER ATV 2004 – 2009 Clymer Owners Service Repair Manual covers the following models: Honda TRX450R 2004-2009 Honda TRX450ER 2006-2009Contents: QUICK REFERENCE DATA GENERAL INFORMATIONManual organization / Warnings cautions and notes / Safety / Serial numbers and information labels / Fasteners / Shop supplies / Tools / Measuring tools / Electrical system fundamentals / Service methods / Storage / Specification Specs TROUBLESHOOTINGStarting the engine / Engine will not start / Poor engine performance / Fuel system / Engine / Engine lubrication / Leakdown test / Clutch / Gearshift linkage / Transmission / Kickstarter / Drive train noise / Electrical testing / Front suspension and steering / Rear suspension / Brake system MAINTENANCE LUBRICATION and TUNE-UPPre-ride inspection / Fuel requirements / Air filter / Engine oil and filter / Oil strainer screen / Transmission oil / Cooling system / Spark plug / Valve clearance / Decompressor clearance / Decompressor system plunger / Engine compression check / Fuel hose and valve / Engine idle speed / Exhaust system / Control cables / Throttle lever free play / Clutch lever free play / Brakes / Drive chain and sprockets / Tyres and wheels / Steering system / Suspension check and lubrication / Skid plate inspection / Nuts bolts and other fasteners / Electrical system / Engine break-in / Specification Specs ENGINE TOP END and EXHAUST SYSTEMExhaust system / Cylinder head cover / Camshaft holder / Camshaft holder service / Cam chain tensioner guides and cam chain / Cylinder head / Valves / Cylinder / Piston and piston rings / Cylinder studs / Specifications ENGINE LOWER END (2004-2005) Engine removal / Engine installation / Countershaft seal / Shift shaft seal / Balancer shaft and primary drive gear assembly / Oil pump drive gear oil pressure relief valve and oil strainer / Crankcase / Crankcase seals and bearings / Oil pump and one-way valve / Crankshaft / Oil cooler and hoses / Specifications ENGINE LOWER END (2006-2009) Engine removal / Engine installation / Countershaft seal / Shift shaft seal / Balancer shaft primary drive gear and starter clutch (TRX450ER) assembly / Oil pump drive gear oil strainer and oil pressure relief valve / Crankcase / Crankcase seals and bearings / Oil pump and one-way valve / Crankshaft / Specifications CLUTCH EXTERNAL SHIFT MECHANISM and KICKSTAR more details…..
